TMS320DM6467T
SPRS605C –JULY 2009–REVISED JUNE 2012
www.ti.com
Table 7-16. DM6467T EDMA Registers (continued)
HEX ADDRESS RANGE ACRONYM REGISTER NAME
0x01C0 2828 EECR Event Enable Clear Register
0x01C0 282C EECRH Event Enable Clear Register High
0x01C0 2830 EESR Event Enable Set Register
0x01C0 2834 EESRH Event Enable Set Register High
0x01C0 2838 SER Secondary Event Register
0x01C0 283C SERH Secondary Event Register High
0x01C0 2840 SECR Secondary Event Clear Register
0x01C0 2844 SECRH Secondary Event Clear Register High
0x01C0 2848 - 0x01C0 284F – Reserved
0x01C0 2850 IER Interrupt Enable Register
0x01C0 2854 IERH Interrupt Enable Register High
0x01C0 2858 IECR Interrupt Enable Clear Register
0x01C0 285C IECRH Interrupt Enable Clear Register High
0x01C0 2860 IESR Interrupt Enable Set Register
0x01C0 2864 IESRH Interrupt Enable Set Register High
0x01C0 2868 IPR Interrupt Pending Register
0x01C0 286C IPRH Interrupt Pending Register High
0x01C0 2870 ICR Interrupt Clear Register
0x01C0 2874 ICRH Interrupt Clear Register High
0x01C0 2878 IEVAL Interrupt Evaluate Register
0x01C0 287C - 0x01C0 287F – Reserved
0x01C0 2880 QER QDMA Event Register
0x01C0 2884 QEER QDMA Event Enable Register
0x01C0 2888 QEECR QDMA Event Enable Clear Register
0x01C0 288C QEESR QDMA Event Enable Set Register
0x01C0 2890 QSER QDMA Secondary Event Register
0x01C0 2894 QSECR QDMA Secondary Event Clear Register
0x01C0 2898 - 0x01C0 29FF – Reserved
Shadow Region 5 Channel Registers
0x01C0 2A00 ER Event Register
0x01C0 2A04 ERH Event Register High
0x01C0 2A08 ECR Event Clear Register
0x01C0 2A0C ECRH Event Clear Register High
0x01C0 2A10 ESR Event Set Register
0x01C0 2A14 ESRH Event Set Register High
0x01C0 2A18 CER Chained Event Register
0x01C0 2A1C CERH Chained Event Register High
0x01C0 2A20 EER Event Enable Register
0x01C0 2A24 EERH Event Enable Register High
0x01C0 2A28 EECR Event Enable Clear Register
0x01C0 2A2C EECRH Event Enable Clear Register High
0x01C0 2A30 EESR Event Enable Set Register
0x01C0 2A34 EESRH Event Enable Set Register High
0x01C0 2A38 SER Secondary Event Register
0x01C0 2A3C SERH Secondary Event Register High
0x01C0 2A40 SECR Secondary Event Clear Register
0x01C0 2A44 SECRH Secondary Event Clear Register High
172 Peripheral Information and Electrical Specifications Copyright © 2009–2012, Texas Instruments Incorporated
