TMS320DM6467T
www.ti.com
SPRS605C –JULY 2009–REVISED JUNE 2012
Table 7-16. DM6467T EDMA Registers (continued)
HEX ADDRESS RANGE ACRONYM REGISTER NAME
0x01C0 2210 ESR Event Set Register
0x01C0 2214 ESRH Event Set Register High
0x01C0 2218 CER Chained Event Register
0x01C0 221C CERH Chained Event Register High
0x01C0 2220 EER Event Enable Register
0x01C0 2224 EERH Event Enable Register High
0x01C0 2228 EECR Event Enable Clear Register
0x01C0 222C EECRH Event Enable Clear Register High
0x01C0 2230 EESR Event Enable Set Register
0x01C0 2234 EESRH Event Enable Set Register High
0x01C0 2238 SER Secondary Event Register
0x01C0 223C SERH Secondary Event Register High
0x01C0 2240 SECR Secondary Event Clear Register
0x01C0 2244 SECRH Secondary Event Clear Register High
0x01C0 2248 - 0x01C0 224F – Reserved
0x01C0 2250 IER Interrupt Enable Register
0x01C0 2254 IERH Interrupt Enable Register High
0x01C0 2258 IECR Interrupt Enable Clear Register
0x01C0 225C IECRH Interrupt Enable Clear Register High
0x01C0 2260 IESR Interrupt Enable Set Register
0x01C0 2264 IESRH Interrupt Enable Set Register High
0x01C0 2268 IPR Interrupt Pending Register
0x01C0 226C IPRH Interrupt Pending Register High
0x01C0 2270 ICR Interrupt Clear Register
0x01C0 2274 ICRH Interrupt Clear Register High
0x01C0 2278 IEVAL Interrupt Evaluate Register
0x01C0 227C - 0x01C0 227F – Reserved
0x01C0 2280 QER QDMA Event Register
0x01C0 2284 QEER QDMA Event Enable Register
0x01C0 2288 QEECR QDMA Event Enable Clear Register
0x01C0 228C QEESR QDMA Event Enable Set Register
0x01C0 2290 QSER QDMA Secondary Event Register
0x01C0 2294 QSECR QDMA Secondary Event Clear Register
0x01C0 2298 - 0x01C0 23FF – Reserved
0x01C0 2400 - 0x01C0 25FF – Reserved
0x01C0 2600 - 0x01C0 27FF – Reserved
Shadow Region 4 Channel Registers
0x01C0 2800 ER Event Register
0x01C0 2804 ERH Event Register High
0x01C0 2808 ECR Event Clear Register
0x01C0 280C ECRH Event Clear Register High
0x01C0 2810 ESR Event Set Register
0x01C0 2814 ESRH Event Set Register High
0x01C0 2818 CER Chained Event Register
0x01C0 281C CERH Chained Event Register High
0x01C0 2820 EER Event Enable Register
0x01C0 2824 EERH Event Enable Register High
Copyright © 2009–2012, Texas Instruments Incorporated Peripheral Information and Electrical Specifications 171
Submit Documentation Feedback
Product Folder Link(s): TMS320DM6467T
