TMS320DM6467T
www.ti.com
SPRS605C –JULY 2009–REVISED JUNE 2012
Table 7-16. DM6467T EDMA Registers (continued)
HEX ADDRESS RANGE ACRONYM REGISTER NAME
0x01C0 04FC Q3E15 Event Q3 Entry 15 Register
0x01C0 0500 - 0x01C0 05FF – Reserved
0x01C0 0600 QSTAT0 Queue 0 Status Register
0x01C0 0604 QSTAT1 Queue 1 Status Register
0x01C0 0608 QSTAT2 Queue 2 Status Register
0x01C0 060C QSTAT3 Queue 3 Status Register
0x01C0 0610 - 0x01C0 061F – Reserved
0x01C0 0620 QWMTHRA Queue Watermark Threshold A Register for Q[3:0]
0x01C0 0624 - 0x01C0 063F – Reserved
0x01C0 0640 CCSTAT EDMA3CC Status Register
0x01C0 0644 - 0x01C0 0FFF – Reserved
Global Channel Registers
0x01C0 1000 ER Event Register
0x01C0 1004 ERH Event Register High
0x01C0 1008 ECR Event Clear Register
0x01C0 100C ECRH Event Clear Register High
0x01C0 1010 ESR Event Set Register
0x01C0 1014 ESRH Event Set Register High
0x01C0 1018 CER Chained Event Register
0x01C0 101C CERH Chained Event Register High
0x01C0 1020 EER Event Enable Register
0x01C0 1024 EERH Event Enable Register High
0x01C0 1028 EECR Event Enable Clear Register
0x01C0 102C EECRH Event Enable Clear Register High
0x01C0 1030 EESR Event Enable Set Register
0x01C0 1034 EESRH Event Enable Set Register High
0x01C0 1038 SER Secondary Event Register
0x01C0 103C SERH Secondary Event Register High
0x01C0 1040 SECR Secondary Event Clear Register
0x01C0 1044 SECRH Secondary Event Clear Register High
0x01C0 1048 - 0x01C0 104F – Reserved
0x01C0 1050 IER Interrupt Enable Register
0x01C0 1054 IERH Interrupt Enable Register High
0x01C0 1058 IECR Interrupt Enable Clear Register
0x01C0 105C IECRH Interrupt Enable Clear Register High
0x01C0 1060 IESR Interrupt Enable Set Register
0x01C0 1064 IESRH Interrupt Enable Set Register High
0x01C0 1068 IPR Interrupt Pending Register
0x01C0 106C IPRH Interrupt Pending Register High
0x01C0 1070 ICR Interrupt Clear Register
0x01C0 1074 ICRH Interrupt Clear Register High
0x01C0 1078 IEVAL Interrupt Evaluate Register
0x01C0 107C - 0x01C0 107F – Reserved
0x01C0 1080 QER QDMA Event Register
0x01C0 1084 QEER QDMA Event Enable Register
0x01C0 1088 QEECR QDMA Event Enable Clear Register
0x01C0 108C QEESR QDMA Event Enable Set Register
