TMS320DM6467T
www.ti.com
SPRS605C –JULY 2009–REVISED JUNE 2012
Table 7-6. Input Requirements for Crystal on the 24-MHz Auxiliary Oscillator (continued)
PARAMETER MIN NOM MAX UNIT
(1)
Frequency Stability ±50 ppm
Parallel Load Capacitance (C1 and C2) [Max] 12 – 20 pF
Frequency Tolerance ± 50 ppm
Aging ± 5 ppm
Thermal Stability ± 50 ppm
Oscillation Mode Fundamental n/a
Drive Level (Max) 0.8 mW
Shunt Capacitance (Max) 5 pF
(1) If the USB is used, a 24-MHz, 50-ppm crystal is recommended.
Copyright © 2009–2012, Texas Instruments Incorporated Peripheral Information and Electrical Specifications 151
Submit Documentation Feedback
Product Folder Link(s): TMS320DM6467T
