TMS320DM6467T
SPRS605C –JULY 2009–REVISED JUNE 2012
www.ti.com
Table 7-4. PSC Registers (continued)
REGISTER
HEX ADDRESS RANGE DESCRIPTION
ACRONYM
0x01C4 1AB4 MDCTL45 Module Control 45 Register (ARM INTC)
0x01C4 1AB8 - 0x01C4 1FFF – Reserved
148 Peripheral Information and Electrical Specifications Copyright © 2009–2012, Texas Instruments Incorporated
Submit Documentation Feedback
Product Folder Link(s): TMS320DM6467T
