TMS320DM6467T
SPRS605C –JULY 2009–REVISED JUNE 2012
www.ti.com
6.2 Recommended Operating Conditions
MIN NOM MAX UNIT
Supply voltage, Core (CV
DD
, DEV_CV
DD
,
CV
DD
(-1G) 1.235 1.3 1.365 V
AUX_CV
DD
)
(1)
Supply voltage, I/O, 3.3V (DV
DD33
, USB_V
DDA3P3
) 3.14 3.3 3.46 V
DV
DD
Supply voltage, I/O, 1.8V (DV
DDR2
, PLL1V
DD18
, PLL2V
DD18
,
1.71 1.8 1.89 V
DEV_DV
DD18
, AUX_DV
DD18
, USB_V
DD1P8
(2)
)
Supply ground (V
SS
, PLL1V
SS
, PLL2V
SS
, DEV_V
SS
(3)
,
V
SS
0 0 0 V
AUX_V
SS
(3)
, USB_V
SSREF
)
DDR_VREF DDR2 reference voltage
(4)
0.49DV
DDR2
0.5DV
DDR2
0.51DV
DDR2
V
DDR2 impedance control, connected via 50-Ω (±5%
DDR_ZP V
SS
V
tolerance) resistor to V
SS
DDR2 impedance control, connected via 50-Ω (±5%
DDR_ZN DV
DDR2
V
tolerance) resistor to DV
DDR2
High-level input voltage, 3.3 V (except JTAG[TCK], PCI-
2 V
capable, and I2C pins)
High-level input voltage, JTAG [TCK] 2.5 V
V
IH
High-level input voltage, PCI 0.5DV
DD33
V
High-level input voltage, I2C 0.7DV
DD33
V
High-level input voltage, non-DDR I/O, 1.8 V 0.65DV
DD18
V
Low-level input voltage, 3.3 V (except PCI-capable and I2C
0.8 V
pins)
Low-level input voltage, PCI 0.3DV
DD33
V
V
IL
Low-level input voltage, I2C 0 0.3DV
DD33
V
Low-level input voltage, non-DDR I/O, 1.8 V 0.35DV
DD18
V
Default 0 85 °C
T
c
Operating case temperature
D Version -40 85 °C
F
SYSCLK1
DSP Operating Frequency (SYSCLK1) -1G 20 1 GHz
(1) Future variants of TI SoC devices may operate at voltages ranging from 0.9 V to 1.4 V to provide a range of system power/performance
options. TI highly recommends that users design-in a supply that can handle multiple voltages within this range (i.e., 1.0 V, 1.05 V,
1.1 V, 1.14 V, 1.2 V, 1.26 V, 1.3 V, 1.365 V with ± 3% tolerances) by implementing simple board changes such as reference resistor
values or input pin configuration modifications. Not incorporating a flexible supply may limit the system's ability to easily adapt to future
versions of TI SoC devices.
(2) Oscillator 1.8 V power supply (DEV_DV
DD18
) can be connected to the same 1.8 V power supply as DV
DDR2
.
(3) Oscillator ground (DEV_V
SS
and AUX_V
SS
) must be kept separate from other grounds and connected directly to the crystal load
capacitor ground.
(4) DDR_VREF is expected to equal 0.5DV
DDR2
of the transmitting device and to track variations in the DV
DDR2
.
136 Device Operating Conditions Copyright © 2009–2012, Texas Instruments Incorporated
Submit Documentation Feedback
Product Folder Link(s): TMS320DM6467T
