TMS320DM6467T
SPRS605C –JULY 2009–REVISED JUNE 2012
www.ti.com
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Reserved
R-0000 0000 0000 0000
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Reserved INTARM0
R-0000 0000 0000 000 R-0
LEGEND: R = Read only, n = Value at reset
Figure 4-23. ARMINT Status Register [0x01C4 0070]
Table 4-42. ARMINT Status Register Bit Descriptions
(1)
BIT NAME DESCRIPTION
31:1 Reserved Reserved. A read returns 0.
0 INTARM0 DSP-to-ARM Int0 Status
(1) Read only, writes have no effect.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Reserved
R-0000 0000 0000 0000
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Reserved INTARM0
R-0000 0000 0000 000 R/W-0
LEGEND: R = Read, W = Write, n = Value at reset
Figure 4-24. ARMINTSET Register [0x01C4 0074]
Table 4-43. ARMINTSET Register Bit Descriptions
BIT NAME DESCRIPTION
31:1 Reserved Reserved. A read returns 0.
0 INTARM0 DSP-to-ARM Int0 Set
(1)
(1) Writing a '1' generates the interrupt and sets the corresponding bit in the ARMINT status register. The register bit automatically clears to
a value of '0'. Writing a '0' has no effect. This register always reads as '0'.
