4.7.3.10 UART2 Pin Muxing
The UART2 module can operate as either a UART or IrDA/CIR interface. The UART2 pin muxing options
are shown in Table 4-36 through Table 4-38. When UART operation is selected, UART2CTL must be set
to either ‘00’ for UART with flow control or ‘01’ for UART without flow control signals. When IrDA/CIR
operation is selected, UART2CTL must be set to ‘10’ to use the IrDA/CIR signals. If UART2 is unused,
then setting UART2CTL = 11 muxes GPIO function onto all the pins. The UART2 pin functions may be
overridden based on the settings of TSPIMUX, CRGMUX, and TSSOMUX.
Table 4-36. UART2 Data Pin Muxing
PIN FUNCTIONS
UTXD2/
URXD2/
URCTX2/
CRGMUX[2] CRGMUX[1] CRGMUX[0] UART2CTL[1] UART2CTL[0]
CRG1_VCXI/
CRG1_PO/
GP[39]/
GP[40]/
CRG0_VCXI
CRG0_PO
0 0 0 0 0 URXD2 UTXD2
0 0 0 0 1 URXD2 UTXD2
0 0 0 1 0 URXD2 URCTX2
0 0 0 1 1 GP[39] GP[40]
0 0 1 0 0 CRG1_VCXI CRG1_PO
0 0 1 0 1 CRG1_VCXI CRG1_PO
0 0 1 1 0 CRG1_VCXI CRG1_PO
0 0 1 1 1 CRG1_VCXI CRG1_PO
0 1 0 0 0 URXD2 UTXD2
0 1 0 0 1 URXD2 UTXD2
0 1 0 1 0 URXD2 URCTX2
0 1 0 1 1 GP[39] GP[40]
0 1 1 0 0 URXD2 UTXD2
0 1 1 0 1 URXD2 UTXD2
0 1 1 1 0 URXD2 URCTX2
0 1 1 1 1 GP[39] GP[40]
1 0 0 0 0 URXD2 UTXD2
1 0 0 0 1 URXD2 UTXD2
1 0 0 1 0 URXD2 URCTX2
1 0 0 1 1 GP[39] GP[40]
1 0 1 0 0 CRG1_VCXI CRG1_PO
1 0 1 0 1 CRG1_VCXI CRG1_PO
1 0 1 1 0 CRG1_VCXI CRG1_PO
1 0 1 1 1 CRG1_VCXI CRG1_PO
1 1 0 0 0 CRG0_VCXI CRG0_PO
1 1 0 0 1 CRG0_VCXI CRG0_PO
1 1 0 1 0 CRG0_VCXI CRG0_PO
1 1 0 1 1 CRG0_VCXI CRG0_PO
1 1 1 0 0 URXD2 UTXD2
1 1 1 0 1 URXD2 UTXD2
1 1 1 1 0 URXD2 URCTX2
1 1 1 1 1 GP[39] GP[40]
