TMS320DM6467T
SPRS605C –JULY 2009–REVISED JUNE 2012
www.ti.com
Table 4-34. UART0 Pin Muxing—Part 2
PIN FUNCTIONS
UDTR0 / UDSR0 / UDCD0 / URIN0/
TSSOMUX[1] TSSOMUX[0] TSPOMUX[1] TSPOMUX[0] UART0CTL[1] UART0CTL[0]
TS0_ENAO/ TS0_PSTO/ TS0_WAITIN/ GP[8]/
GP[36] GP[37] GP[38] TS1_WAITIN
0 x 0 x 0 0 UDTR0 UDSR0 UDCD0 URIN0
0 x 0 x 0 1 GP[36] GP[37] GP[38] GP[8]
0 x 0 x 1 0 GP[36] GP[37] GP[38] GP[8]
0 x 0 x 1 1 GP[36] GP[37] GP[38] GP[8]
0 x 1 x 0 0 TS0_ENAO TS0_PSTO TS0_WAITIN GP[8]
0 x 1 x 0 1 TS0_ENAO TS0_PSTO TS0_WAITIN GP[8]
0 x 1 x 1 0 TS0_ENAO TS0_PSTO TS0_WAITIN GP[8]
0 x 1 x 1 1 TS0_ENAO TS0_PSTO TS0_WAITIN GP[8]
1 0 0 x 0 0 UDTR0 UDSR0 UDCD0 URIN0
1 0 0 x 0 1 GP[36] GP[37] GP[38] GP[8]
1 0 0 x 1 0 GP[36] GP[37] GP[38] GP[8]
1 0 0 x 1 1 GP[36] GP[37] GP[38] GP[8]
1 0 1 x 0 0 TS0_ENAO TS0_PSTO TS0_WAITIN GP[8]
1 0 1 x 0 1 TS0_ENAO TS0_PSTO TS0_WAITIN GP[8]
1 0 1 x 1 0 TS0_ENAO TS0_PSTO TS0_WAITIN GP[8]
1 0 1 x 1 1 TS0_ENAO TS0_PSTO TS0_WAITIN GP[8]
1 1 0 x 0 0 UDTR0 UDSR0 UDCD0 TS1_WAITIN
1 1 0 x 0 1 GP[36] GP[37] GP[38] TS1_WAITIN
1 1 0 x 1 0 GP[36] GP[37] GP[38] TS1_WAITIN
1 1 0 x 1 1 GP[36] GP[37] GP[38] TS1_WAITIN
1 1 1 x 0 0 TS0_ENAO TS0_PSTO TS0_WAITIN TS1_WAITIN
1 1 1 x 0 1 TS0_ENAO TS0_PSTO TS0_WAITIN TS1_WAITIN
1 1 1 x 1 0 TS0_ENAO TS0_PSTO TS0_WAITIN TS1_WAITIN
1 1 1 x 1 1 TS0_ENAO TS0_PSTO TS0_WAITIN TS1_WAITIN
