4.7.3.3 TSIF0 Input Signal Muxing (Serial/Parallel)
The TSIF 0 (TS0) input signals have muxing options for both parallel or serial operation as configured by
the TPSIMUX bits as shown in Table 4-28.
Table 4-28. TSIF0 Input Pin Muxing
TSPIMUX = 0x TSPIMUX = 10 TSPIMUX = 11
(NO TSIF0 SIGNALS ENABLED) (PARALLEL) (SERIAL)
TS0_CLKIN TS0_CLKIN TS0_CLKIN
VP_DIN15_VSYNC TS0_DIN7 VP_DIN15_VSYNC
VP_DIN14_HSYNC TS0_DIN6 VP_DIN14_HSYNC
VP_DIN13_FIELD TS0_DIN5 VP_DIN13_FIELD
VP_DIN12 TS0_DIN4 VP_DIN12
VP_DIN11 TS0_DIN3 VP_DIN11
VP_DIN10 TS0_DIN2 VP_DIN10
VP_DIN9 TS0_DIN1 VP_DIN9
VP_DIN8 TS0_DIN0 VP_DIN8
URXD1
(1)
URXD1
(1)
TS0_DIN7
UTXD1
(1)
UTXD1
(1)
(see Table 4-22—TSPOMUX bit
field)
(also see Table 4-35)
URTS1
(1)
TS0_WAITO TS0_WAITO
UCTS1
(1)
TS0_EN_WAITO TS0_EN_WAITO
URTS2
(2)
TS0_PSTIN TS0_PSTIN
(1) Function is determined by UART1CTL bit field value in the PINMUX0 register.
(2) Function is determined by UART2CTL bit field value in the PINMUX0 register.
