4.7.3.2 PWM Signal Muxing
The two PWM outputs will be configured as PWM pin functions by default. The PWM functions may be
overridden by the settings of various PINMUX0 bit fields as shown in Table 4-26 and Table 4-27.
Table 4-26. PWM0 Pin Muxing
PIN FUNCTION
CRGMUX ≠ 10x CRGMUX = 10x
TSSOMUX = 11
TSSOMUX ≠ 11 TSSOMUX ≠ 11
PWM0 CRG0_PO TS1_ENAO
Table 4-27. PWM1 Pin Muxing
PIN FUNCTION
TSSOMUX ≠ 11 TSSOMUX = 11
PWM1 TS1_DOUT
