Table 4-25. PCI, HPI, EMIFA, and ATA Pin Muxing (continued)
PIN FUNCTIONS (WITH PCIEN, HPIEN, ATAEN VALUES)
1xx
(1)
010 011 000 001
PCI_AD26 HD26 DD10 EM_A[10] DD10
PCI_AD25 HD25 DD9 EM_A[9] DD9
PCI_AD24 HD24 DD8 EM_A[8] DD8
PCI_AD23 HD23 DD7 EM_A[7] DD7
PCI_AD22 HD22 DD6 EM_A[6] DD6
PCI_AD21 HD21 DD5 EM_A[5] DD5
PCI_AD20 HD20 DD4 EM_A[4] DD4
PCI_AD19 HD19 DD3 EM_A[3] DD3
PCI_AD18 HD18 DD2 EM_A[2] DD2
PCI_AD17 HD17 DD1 EM_A[1] DD1
PCI_AD16 HD16 DD0 EM_A[0] DD0
PCI_AD15 HD15 HD15 EM_D15 EM_D15
PCI_AD14 HD14 HD14 EM_D14 EM_D14
PCI_AD13 HD13 HD13 EM_D13 EM_D13
PCI_AD12 HD12 HD12 EM_D12 EM_D12
PCI_AD11 HD11 HD11 EM_D11 EM_D11
PCI_AD10 HD10 HD10 EM_D10 EM_D10
PCI_AD9 HD9 HD9 EM_D9 EM_D9
PCI_AD8 HD8 HD8 EM_D8 EM_D8
PCI_AD7 HD7 HD7 EM_D7 EM_D7
PCI_AD6 HD6 HD6 EM_D6 EM_D6
PCI_AD5 HD5 HD5 EM_D5 EM_D5
PCI_AD4 HD4 HD4 EM_D4 EM_D4
PCI_AD3 HD3 HD3 EM_D3 EM_D3
PCI_AD2 HD2 HD2 EM_D2 EM_D2
PCI_AD1 HD1 HD1 EM_D1 EM_D1
PCI_AD0 HD0 HD0 EM_D0 EM_D0
PCI_RST GP[13] DA2 EM_A[22] DA2
PCI_RSV0
(2)
GP[16] DA1 EM_A[21] DA1
PCI_RSV1
(2)
GP[17] DA0 EM_A[20] DA0
PCI_RSV2
(2)
GP[18] INTRQ EM_RSV0 INTRQ
PCI_RSV3
(2)
GP[19] DIOR EM_WAIT5/(RDY5/BSY5) DIOR
PCI_RSV4
(2)
GP[20] DIOW EM_WAIT4/(RDY4/BSY4) DIOW
PCI_RSV5
(2)
GP[21] IORDY EM_WAIT3/(RDY3/BSY3) IORDY
(2) In PCI mode (PCIEN = 1), the internal pullups/pulldowns (IPUs/IPDs) are disabled on all PCI pins and it is recommended to have
external pullup resistors on the PCI_RSV[5:0] pins. For more detailed information on external pullup/pulldown resistors, see
Section 4.8.1, Pullup/Pulldown Resistors.
