TMS320DM6467T
www.ti.com
SPRS605C –JULY 2009–REVISED JUNE 2012
Table 4-22. PINMUX0 Register Bit Descriptions
BIT NAME DESCRIPTION
This bit disables USB_DRVVBUS output.
31 VBUSDIS 0 = USB_DRVVBUS function selected.
1 = GP[22] function selected.
This bit enables STC Source Clock input.
30 STCCK 0 = GP[4] function selected.
1 = STC_CLKIN function selected.
This bit enables AUDIO_CLK1 output.
29 AUDCK1 0 = GP[2] function selected.
1 = AUDIO_CLK1 function selected.
This bit enables AUDIO_CLK0 output.
28 AUDCK0 0 = GP[3] function selected.
1 = AUDIO_CLK0 function selected.
27 RSV Reserved. Read returns "0".
CRGEN Pin Mux Control (see Section 4.7.3.7, CRGEN Signal Muxing).
000 = No CRGEN signals enabled.
001 = CRGEN1 selection enabled (muxed with UART2 data).
010 = Reserved (no CRGEN signals enabled).
26:24 CRGMUX 011 = Reserved (no CRGEN signals enabled).
100 = CRGEN0 selection enabled (muxed with UCTS2 and PWM0).
101 = CRGEN0 and CRGEN1 selection enabled.
110 = CRGEN0 selection enabled (muxed with UART2 data).
111 = Reserved (no CRGEN signals enabled).
TSIF1 Serial Output Pin Mux Control (see
(1)
, TSSO Signal Muxing).
0x = No TS1 output signals enabled.
23:22 TSSOMUX
10 = TS1 output selection enabled (muxed on VP_DOUT pins).
11 = TS1 output selection enabled (muxed on URIN0, UCTS2, PWM0, and PWM1 pins).
TSIF1 Serial Input Pin Mux Control (see Section 4.7.3.5, TSIF1 Input Signal Muxing).
00 = No TS1 input signals enabled.
21:20 TSSIMUX 01 = TS1 input selection enabled (muxed on UART0 pins).
10 = TS1 input selection enabled (muxed on VP_DOUT pins).
11 = TS1 input selection enabled (muxed on VP_DIN pins).
TSIF0 Parallel/Serial Output Pin Mux Control (see Section 4.7.3.4, TSIF0 Output Signal Muxing).
0x = No TS0 output signals enabled.
19:18 TSPOMUX
10 = TS0 parallel output muxing enabled (muxed with VP_DIN pins).
11 = TS0 serial output muxing enabled (muxed TS0_DOUT7 with UTXD1).
TSIF0 Parallel/Serial Input Pin Mux Control (see Section 4.7.3.3, TSIF0 Input Signal Muxing).
0x = No TS0 signals enabled.
17:16 TSPIMUX
10 = TS0 parallel input muxing enabled (muxed with VP_DIN pins).
11 = TS0 serial input muxing enabled (muxed TS0_DIN7 with URXD1).
15:6 RESERVED Reserved. Read returns "0".
Reserved. Read returns "0". Note: For proper device operation, when writing to this bit, only a "0"
5 RESERVED
should be written.
4:3 RESERVED Reserved. Read returns "0".
PCI Function Enable (see Section 4.7.3.1, PCI, HPI, EMIFA and ATA Pin Muxing).
2 PCIEN
Default value is determined by PCIEN boot configuration pin.
1 HPIEN HPI Function Enable (see Section 4.7.3.1, PCI, HPI, EMIFA and ATA Pin Muxing).
0 ATAEN ATA Function Enable (see Section 4.7.3.1, PCI, HPI, EMIFA and ATA Pin Muxing).
(1) IPD = Internal pulldown, IPU = Internal pullup. For more detailed information on pullup/pulldown resistors and situations where external
pullup/pulldown resistors are required, see Section 4.8.1, Pullup/Pulldown Resistors.
Copyright © 2009–2012, Texas Instruments Incorporated Device Configurations 111
Submit Documentation Feedback
Product Folder Link(s): TMS320DM6467T
