TMS320DM6467T
www.ti.com
SPRS605C –JULY 2009–REVISED JUNE 2012
4.6.2.4 EDMATCCFG Register
The EDMA Transfer Controller Default Burst Size Configuration Register (EDMATCCFG) [0x01C4 0058]
configures the default burst size (DBS) for EDMA TC0, EDMA TC1, EDMA TC2, and EDMA TC3.
Figure 4-17 and Table 4-21 describe in detail the EDMATCCFG register. For more information on the
correct usage of DBS, see the TMS320DM646x DMSoC Enhanced Direct Memory Access (EDMA)
Controller User's Guide (literature number SPRUEQ5).
31 16
RESERVED
R-0000 0000 0000 0000
15 8 7 6 5 4 3 2 1 0
RESERVED TC3DBS TC2DBS TC1DBS TC0DBS
R-0000 0000 R/W-01 R/W-01 R/W-01 R/W-01
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Figure 4-17. EDMA Transfer Controller Default Burst Size Configuration Register (EDMATCCFG)
[0x01C4 0058]
Table 4-21. EDMATCCFG Register Bit Descriptions
BIT NAME DESCRIPTION
31:8 RESERVED Reserved. Read-only, writes have no effect.
EDMA TC3 Default Burst Size.
00 = 16 byte
01 = 32 byte [default]
7:6 TC3DBS
10 = 64 byte
11 = reserved
TC3 FIFO size is 256 bytes, regardless of Default Burst Size setting.
EDMA TC2 Default Burst Size.
00 = 16 byte
01 = 32 byte [default]
5:4 TC2DBS
10 = 64 byte
11 = reserved
TC2 FIFO size is 256 bytes, regardless of Default Burst Size setting.
EDMA TC1 Default Burst Size.
00 = 16 byte
01 = 32 byte [default]
3:2 TC1DBS
10 = 64 byte
11 = reserved
TC1 FIFO size is 256 bytes, regardless of Default Burst Size setting.
EDMA TC0 Default Burst Size.
00 = 16 byte
01 = 32 byte [default]
1:0 TC0DBS
10 = 64 byte
11 = reserved
TC0 FIFO size is 256 bytes, regardless of Default Burst Size setting.
