TMS320DM6467T
www.ti.com
SPRS605C –JULY 2009–REVISED JUNE 2012
Table 4-19. USBCTL Register Bit Descriptions
BIT NAME DESCRIPTION
31:19 RESERVED Reserved. Read returns "0".
USB Data Polarity.
18 DATAPOL 0 = Inverted data.
1 = Normal data polarity [default].
VBUS Sense Control.
17 VBUSVAL 0 = Disabled [default].
1 = Session starts.
USB Mode.
16 USBID 0 = Host [default].
1 = Peripheral.
15:9 RESERVED Reserved. Read returns "0".
USB PHY Power and Clock Good.
8 PHYCLKGD 0 = PHY power is not ramped or PLL is not locked [default].
1 = PHY power is good and PLL is locked.
7:5 RESERVED Reserved. Read returns "0".
USB PHY PLL Suspend Override.
4 PHYPLLON 0 = Normal PLL operation [default].
1 = Override PLL suspend state.
3:1 RESERVED Reserved. Read returns "0".
USB PHY Power-Down Control.
0 PHYPDWN 0 = PHY powered on.
1 = PHY power off [default].
