TMS320DM6467T
www.ti.com
SPRS605C –JULY 2009–REVISED JUNE 2012
31 30 28 27 26 24 23 22 20 19 18 16
RSV TSIF1P RSV TSIF0P RSV VP1P RSV VP0P
R-0 R/W-001 R-0 R/W-001 R-0 R/W-001 R-0 R/W-001
15 14 12 11 10 8 7 6 4 3 2 0
RSV EDMATC3P RSV EDMATC2P RSV EDMATC1P RSV EDMATC0P
R-0 R/W-010 R-0 R/W-010 R-0 R/W-010 R-0 R/W-010
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Figure 4-13. MSTPRI2 Register
Table 4-17. MSTPRI2 Register Bit Descriptions
BIT NAME DESCRIPTION
31 RSV Reserved. Read returns "0".
30:28 TSIF1P TSIF1 master port priority in System Infrastructure.
000 = Priority 0 (Highest) 100 = Priority 4
001 = Priority 1 [Default] 101 = Priority 5
010 = Priority 2 110 = Priority 6
011 = Priority 3 111 = Priority 7 (Lowest)
27 RSV Reserved. Read returns "0".
26:24 TSIF0P TSIF0 master port priority in System Infrastructure.
000 = Priority 0 (Highest) 100 = Priority 4
001 = Priority 1 [Default] 101 = Priority 5
010 = Priority 2 110 = Priority 6
011 = Priority 3 111 = Priority 7 (Lowest)
23 RSV Reserved. Read returns "0".
VPIF display master port priority in System Infrastructure. Same priority 0–7 selection as above.
22:20 VP1P
"001" = Priority 1 [default].
19 RSV Reserved. Read returns "0".
VPIF capture master port priority in System Infrastructure. Same priority 0–7 selection as above.
18:16 VP0P
"001" = Priority 1 [default].
15 RSV Reserved. Read returns "0".
EDMATC3 master port priority in System Infrastructure. Same priority 0–7 selection as above.
14:12 EDMATC3P
"010" = Priority 2 [default].
11 RSV Reserved. Read returns "0".
EDMATC2 master port priority in System Infrastructure. Same priority 0–7 selection as above.
10:8 EDMATC2P
"010" = Priority 2 [default].
7 RSV Reserved. Read returns "0".
EDMATC1 master port priority in System Infrastructure. Same priority 0–7 selection as above.
6:4 EDMATC1P
"010" = Priority 2 [default].
3 RSV Reserved. Read returns "0".
EDMATC0 master port priority in System Infrastructure. Same priority 0–7 selection as above.
2:0 EDMATC0P
"010" = Priority 2 [default].
4.6.2 Peripheral Selection After Device Reset
After device reset, most peripheral configurations are done within the peripheral’s registers. This
section discusses some additional peripheral controls in the System Module. For information on
multiplexed pin controls that determine what peripheral pins are brought out to the pins, see
Section 4.7, Multiplexed Pin Configurations.
