TMS320DM6467T
www.ti.com
SPRS605C –JULY 2009–REVISED JUNE 2012
31 23 22 20 19 18 16
RESERVED RSV
HDVICP1P
(1)
HDVICP0P
(1)
R-0000 0000 0 R/W-011 R-0 R/W-011
15 14 12 11 8 7 6 4 3 2 0
RSV DSPDMAP RSV DSPCFGP
(1)
RSV ARMDATAP RSV ARMINSTP
R-0 R/W-100 R-0 R/W-100 R-0 R/W-100 R-0 R/W-100
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Figure 4-11. MSTPRI0 Register [0x01C4 003C]
(1) The DSPCFGP, HDVICP0P, and HDVICP1P priority values are not actually used by the infrastructure, which gives equal weight round-
robin priority to accesses from this master; therefore, the settings have no effect.
Table 4-15. MSTPRI0 Register Bit Descriptions
BIT NAME DESCRIPTION
31:23 RESERVED Reserved. Read returns "0".
22:20 HDVICP1P
(1)
HDVICP1 master port priority in System Infrastructure. Read returns "011". Writes have no effect.
19 RSV Reserved. Read returns "0".
18:16 HDVICP0P
(1)
HDVICP0 master port priority in System Infrastructure. Read returns "011". Writes have no effect.
15 RSV Reserved. Read returns "0".
14:12 DSPDMAP DSPDMA master port priority in System Infrastructure.
000 = Priority 0 (Highest) 100 = Priority 4 [Default]
001 = Priority 1 101 = Priority 5
010 = Priority 2 110 = Priority 6
011 = Priority 3 111 = Priority 7 (Lowest)
11 RSV Reserved. Read returns "0".
10:8 DSPCFGP
(1)
DSPCFG master port priority in System Infrastructure. Read returns "100". Writes have no effect.
7 RSV Reserved. Read returns "0".
6:4 ARMDATAP ARM DATA master port priority in System Infrastructure.
000 = Priority 0 (Highest) 100 = Priority 4 [Default]
001 = Priority 1 101 = Priority 5
010 = Priority 2 110 = Priority 6
011 = Priority 3 111 = Priority 7 (Lowest)
3 RSV Reserved. Read returns "0".
2:0 ARMINSTP ARM INST master port priority in System Infrastructure.
000 = Priority 0 (Highest) 100 = Priority 4 [Default]
001 = Priority 1 101 = Priority 5
010 = Priority 2 110 = Priority 6
011 = Priority 3 111 = Priority 7 (Lowest)
(1) The priorities for these masters are fixed at their default values. Writing alternate values to these fields has no effect..
