TMS320DM6467T

www.ti.com

SPRS605C –JULY 2009–REVISED JUNE 2012

TMS320DM6467T

Digital Media System-on-Chip

Check for Samples: TMS320DM6467T

1 Digital Media System-on-Chip (DMSoC)

1.1 Features

– 128K-Byte L2 Unified Mapped RAM/Cache

• High-Performance Digital Media SoC

(Flexible RAM/Cache Allocation)

– 1-GHz C64x+™ Clock Rate

• ARM926EJ-S Core

– 500-MHz ARM926EJ-S™ Clock Rate

– Support for 32-Bit and 16-Bit (Thumb®

– Eight 32-Bit C64x+ Instructions/Cycle

Mode) Instruction Sets

– 8000 C64x+ MIPS

– DSP Instruction Extensions and Single Cycle

– Fully Software-Compatible With C64x /

MAC

ARM9™

– ARM® Jazelle® Technology

– Industrial Temperature Devices Available

– EmbeddedICE-RT™ Logic for Real-Time

• Advanced Very-Long-Instruction-Word (VLIW)

Debug

TMS320C64x+™ DSP Core

• ARM9 Memory Architecture

– Eight Highly Independent Functional Units

– 16K-Byte Instruction Cache

• Six ALUs (32-/40-Bit), Each Supports

– 8K-Byte Data Cache

Single 32-Bit, Dual 16-Bit, or Quad 8-Bit

– 32K-Byte RAM

Arithmetic per Clock Cycle

– 8K-Byte ROM

• Two Multipliers Support Four 16 x 16-Bit

Multiplies (32-Bit Results) per Clock • Embedded Trace Buffer™ (ETB11™) With 4KB

Cycle or Eight 8 x 8-Bit Multiplies (16-Bit Memory for ARM9 Debug

Results) per Clock Cycle

• Endianness: Little Endian for ARM and DSP

– Load-Store Architecture With Non-Aligned

• Dual Programmable High-Definition Video

Support

Image Co-Processor (HDVICP) Engines

– 64 32-Bit General-Purpose Registers

– Supports a Range of Encode, Decode, and

– Instruction Packing Reduces Code Size Transcode Operations

– All Instructions Conditional • H.264, MPEG2, VC1, MPEG4 SP/ASP

– Additional C64x+™ Enhancements • 150-MHz Video Port Interface (VPIF)

• Protected Mode Operation – Two 8-Bit SD (BT.656), Single 16-Bit HD

(BT.1120), or Single Raw (8-/10-/12-Bit) Video

• Exceptions Support for Error Detection

Capture Channels

and Program Redirection

– Two 8-Bit SD (BT.656) or Single 16-Bit HD

• Hardware Support for Modulo Loop

(BT.1120) Video Display Channels

Operation

• Video Data Conversion Engine (VDCE)

• C64x+ Instruction Set Features

– Horizontal and Vertical Downscaling

– Byte-Addressable (8-/16-/32-/64-Bit Data)

– Chroma Conversion (4:2:2↔4:2:0)

– 8-Bit Overflow Protection

• Two Transport Stream Interface (TSIF) Modules

– Bit-Field Extract, Set, Clear

(One Parallel/Serial and One Serial Only)

– Normalization, Saturation, Bit-Counting

– TSIF for MPEG Transport Stream

– Compact 16-Bit Instructions

– Simultaneous Synchronous or

– Additional Instructions to Support Complex

Asynchronous Input/Output Streams

Multiplies

– Absolute Time Stamp Detection

• C64x+ L1/L2 Memory Architecture

– PID Filter With 7 PID Filter Tables

– 32K-Byte L1P Program RAM/Cache (Direct

– Corresponding Clock Reference Generator

Mapped)

(CRGEN) Modules for System Time-Clock

– 32K-Byte L1D Data RAM/Cache (2-Way Set-

Recovery

Associative)

Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of

Texas Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.

2All trademarks are the property of their respective owners.

PRODUCTION DATA information is current as of publication date. Products conform to

specifications per the terms of the Texas Instruments standard warranty. Production

processing does not necessarily include testing of all parameters.
