TLK1221
SLLS713C –FEBRUARY 2007–REVISED SEPTEMBER 2009....................................................................................................................................... www.ti.com
ABSOLUTE MAXIMUM RATINGS
over operating free-air temperature range (unless otherwise noted)
VALUE
(1)
UNIT
V
DD
Supply voltage
(2)
–0.3 to 3 V
V
I
Input voltage range at TTL terminals –0.5 to 4 V
V
I
Input voltage range at other terminals –0.3 to V
DD
+ 0.3 V
ESD Electrostatic discharge CDM: 1, HBM: 2 kV
T
stg
Storage temperature –65 to 150 °C
T
A
Characterized free-air temperature range –40 to 85 °C
(1) Stresses beyond those listed under Absolute Maximum Ratings may cause permanent damage to the device. These are stress ratings
only, and functional operation of the device at these or any other conditions beyond those indicated under Recommended Operating
Conditions is not implied. Exposure to absolute-maximum-rated conditions for extended periods may affect device reliability.
(2) All voltage values, except differential I/O bus voltages, are with respect to network ground terminal.
DISSIPATION RATINGS
T
A
≤ 25°C DERATING FACTOR T
A
= 70°C T
A
= 85°C
PACKAGE
POWER RATING ABOVE T
A
= 25°C POWER RATING POWER RATING
RHA
(1) (2)
2.85 W 28 mW/°C 1.57 W 1.4 W
(1) The thermal resistance junction to ambient of the RHA package is 35°C/W measured on a high-K board.
(2) The thermal resistance junction-to-case (exposed pad) of the RHA package is 5°C/W.
RECOMMENDED OPERATING CONDITIONS
over operating free-air temperature range (unless otherwise noted)
MIN NOM MAX UNIT
V
DD
,
V
DDA
, Supply voltage 2.3 2.5 2.7 V
V
DDPLL
I
DD
, I
DDA
, Frequency = 1.25 Gbps, PRBS pattern;
Total supply current 113 mA
I
DDPLL
ENABLE = 1, V
DD
, V
DDPLL
and V
DDA
= 2.7 V
P
D
Total power dissipation Frequency = 1.25 Gbps, PRBS pattern 235 305 mW
I
DDQ
Total shutdown current (I
DD
+I
DDA
+ I
DDPLL
) Enable = 0; V
DD
, V
DDPLL
and V
DDA
= 2.7 V 1000 μA
PLL Startup lock time V
DD
, V
DDA
= 2.5 V 500 μs
T
A
Operating free-air temperature –40 85 °C
REFERENCE CLOCK (REFCLK) TIMING REQUIREMENTS
over recommended operating conditions (unless otherwise noted)
PARAMETER TEST CONDITIONS MIN TYP MAX UNIT
Minimum data rate TYP – 0.01% 60 TYP + 0.01%
f Frequency MHz
Maximum data rate TYP – 0.01% 130 TYP + 0.01%
Accuracy –100 100 ppm
DC Duty cycle 40% 50% 60%
Jitter Random plus deterministic 40 ps
