TLK1221
www.ti.com
....................................................................................................................................... SLLS713C –FEBRUARY 2007–REVISED SEPTEMBER 2009
REVISION HISTORY
Changes from Original (February 2007) to Revision A .................................................................................................. Page
• Added Fast Relock Times Less to list of Features ............................................................................................................... 1
• Changed Last two items in the Differenvces list ................................................................................................................... 2
• Changed Data relock time in the Transmitter Characteristics .............................................................................................. 9
Changes from Revision A (June 2007) to Revision B .................................................................................................... Page
• Changed From: The minimum latency in TBI mode is 19 bit times. The maximum latency in TBI mode is 20 bit
times. To: The minimum latency in TBI mode is 20 bit times. The maximum latency in TBI mode is 22 bit times ............. 3
• Changed From: The minimum latency in TBI mode is 21 bit times and the maximum latency is 31 bit times. To: The
minimum latency in TBI mode is 18 bit times and the maximum latency is 24 bit times. .................................................... 5
Changes from Revision B (March 2009) to Revision C .................................................................................................. Page
• Changed Pin Function Table - Enable Pin I/O From: P/D to P/U ......................................................................................... 7
Copyright © 2007–2009, Texas Instruments Incorporated Submit Documentation Feedback 15
Product Folder Link(s): TLK1221
