- FEATURES
- APPLICATIONS
- DESCRIPTION/ORDERING INFORMATION
- ABSOLUTE MAXIMUM RATINGS
- RECOMMENDED OPERATING CONDITIONS
- TL4050x25I ELECTRICAL CHARACTERISTICS
- TL4050x25Q ELECTRICAL CHARACTERISTICS
- TL4050x41I ELECTRICAL CHARACTERISTICS
- TL4050x41Q ELECTRICAL CHARACTERISTICS
- TL4050x50I ELECTRICAL CHARACTERISTICS
- TL4050x50Q ELECTRICAL CHARACTERISTICS
- TL4050x10I ELECTRICAL CHARACTERISTICS
- TL4050x10Q ELECTRICAL CHARACTERISTICS
- TYPICAL CHARACTERISTICS
- APPLICATION INFORMATION
TL4050
SLOS486A – JUNE 2007 – REVISED AUGUST 2009 ........................................................................................................................................................
www.ti.com
ORDERING INFORMATION
(1)
DEVICE ORDERABLE TOP-SIDE
T
A
V
KA
PACKAGE
(2)
GRADE PART NUMBER MARKING
(3)
Reel of 3000 TL4050A25IDBZR
SOT-23-3 – DBZ TKE_
Reel of 250 TL4050A25IDBZT
2.5 V
Reel of 3000 TL4050A25IDCKR
SC-70 – DCK 82_
Reel of 250 TL4050A25IDCKT
Reel of 3000 TL4050A41IDBZR
SOT-23-3 – DBZ TKL_
Reel of 250 TL4050A41IDBZT
4.096 V
A grade:
Reel of 3000 TL4050A41IDCKR
0.1% initial
SC-70 – DCK 8E_
Reel of 250 TL4050A41IDCKT
accuracy and
50 ppm/ ° C
Reel of 3000 TL4050A50IDBZR
SOT-23-3 – DBZ TKS_
temperature
Reel of 250 TL4050A50IDBZT
coefficient
5 V
Reel of 3000 TL4050A50IDCKR
SC-70 – DCK 8L_
Reel of 250 TL4050A50IDCKT
Reel of 3000 TL4050A10IDBZR
SOT-23-3 – DBZ TK2_
Reel of 250 TL4050A10IDBZT
10 V
Reel of 3000 TL4050A10IDCKR
SC-70 – DCK 8Z_
Reel of 250 TL4050A10IDCKT
– 40 ° C to 85 ° C
Reel of 3000 TL4050B25IDBZR
SOT-23-3 – DBZ TKF_
Reel of 250 TL4050B25IDBZT
2.5 V
Reel of 3000 TL4050B25IDCKR
SC-70 – DCK 83_
Reel of 250 TL4050B25IDCKT
Reel of 3000 TL4050B41IDBZR
SOT-23-3 – DBZ TKM_
Reel of 250 TL4050B41IDBZT
4.096 V
B grade:
Reel of 3000 TL4050B41IDCKR
0.2% initial
SC-70 – DCK 8F_
Reel of 250 TL4050B41IDCKT
accuracy and
50 ppm/ ° C
Reel of 3000 TL4050B50IDBZR
SOT-23-3 – DBZ TKT_
temperature
Reel of 250 TL4050B50IDBZT
coefficient
5 V
Reel of 3000 TL4050B50IDCKR
SC-70 – DCK 8M_
Reel of 250 TL4050B50IDCKT
Reel of 3000 TL4050B10IDBZR
SOT-23-3 – DBZ TK3_
Reel of 250 TL4050B10IDBZT
10 V
Reel of 3000 TL4050B10IDCKR
SC-70 – DCK 92_
Reel of 250 TL4050B10IDCKT
(1) For the most current package and ordering information, see the Package Option Addendum at the end of this document, or see the TI
web site at www.ti.com .
(2) Package drawings, thermal data, and symbolization are available at www.ti.com/packaging .
(3) The actual top-side marking has one additional character that designates the wafer fab/assembly site.
