1.1 TAS5352DDV6EVM Features
Overview
This 5-channel system plus subwoofer line output is designed for home theater applications such as A/V
receivers, DVD receivers, DVD minicomponent systems, or home theater in a box (HTIB).
This document covers EVM specifications, audio performance and power efficiency measurements
graphs, and design documentation that includes schematics, parts list, layout, and mechanical design.
Gerber (layout) files are available at www.ti.com .
The EVM is delivered with cables and an Input-USB board 2 to connect to an input source and be
controlled from a PC.
• 5/6-channel PurePath Digital™ evaluation module
• Subwoofer line output (LFE output)
• Self-contained protection system (short circuit and thermal)
• Standard I
2
S™ and I
2
C™/control connector for TI input board
• Double-sided plated-through PCB layout
