TAS5352DDV6EVM Partslist (2.00)
ti
5 J101 J102 J103 J104 J117
2 pins / 1 row / 3.96mm Pitch Vertical Male Pin
header Header JST B2P-VH
1 J901
4 pins / 1 row / 3.96mm Pitch Vertical Male Pin
header Header JST B4P-VH
1 J600 Horizontal Female w. Switch Coax Phono socket Chunfeng RJ843-4W
1 J10 profile IDC 26 pins IDC Box header Molex 87834-2611
1 X10 13.5MHz 13.5MHz SMD Crystal (HCM49
)
Citize
n
HCM49-13.500MABJ
T
1 PCB1
A
831-PCB-001_1.00 / TAS5352DDV6EVM Printed
Circuit Board (ver. 1.00) Printline A831-PCB-001(1.00)
1 HEATSINK630
TIC-HSINK-053_1.00 / Heatsink for 3 DDV
packages length 114 mm Phonotech TIC-HSINK-053(1.00)
2 of 2
20.Dec.2007 / JLH
