- 5 Related Documentation from Texas Instruments
- Appendix A Design Documents
www.ti.com
5 Related Documentation from Texas Instruments
5.1 Additional Documentation
Related Documentation from Texas Instruments
Table 11 contains a list of data sheets that have detailed descriptions of the integrated circuits used in the
design of the TAS5352DDV6EVM. The data sheets can be obtained at the URL http://www.ti.com .
Table 11. Related Documentation From Texas
Instruments
Part Number Literature Number
TAS5518 SLES115
TAS5352 SLES204
DRV600 SLOS536
TLV271 SLOS351
TPS3825-33 SLVS165
TLV1117-33C SLVS561
1. PC Configuration Tool for TAS5518 (TAS5518 GUI ver. 4.0 or later)
2. System Design Considerations for True Digital Audio Power Amplifiers application report (SLAA117 )
3. Digital Audio Measurements application report (SLAA114 )
4. PSRR for PurePath Digital Audio Amplifiers application report (SLEA049 }
5. Power Rating in Audio Amplifier application report (SLEA047 )
6. PurePath Digital AM Interference Avoidance application report (SLEA040 )
7. Click and Pop Measurements Technique application report (SLEA044 )
8. Power Supply Recommendations for DVD-Receivers application report (SLEA027 )
9. Implementation of Power Supply Volume Control application report (SLEA038 )
24 TAS5352DDV6EVM SLAU244 – March 2008
