4.20 Pop/Click (BTL)
-40m
40m
-35m
-30m
-25m
-20m
-15m
-10m
-5m
0
5m
10m
15m
20m
25m
30m
35m
0 4m500u 1m 1.5m 2m 2.5m 3m 3.5m
t-Time-s
Voltage-V
4.21 Pop/Click (PBTL)
-40m
40m
-35m
-30m
-25m
-20m
-15m
-10m
-5m
0
5m
10m
15m
20m
25m
30m
35m
0 4m500u 1m 1.5m 2m 2.5m 3m 3.5m
t-Time-s
Voltage-V
TAS5352DDV6EVM Performance
No input signal is applied. The measurement results are presented in frequency domain.
Test with automute disabled – Register x04h set to x60h. No input signal is applied. Load is 4 Ω .
Figure 23. Pop/Click (BTL)
No input signal is applied. The measurement results are presented in frequency domain.
Test with automute disabled – Register x04h set to x60h. No input signal is applied. Load is 2 Ω .
Figure 24. Pop/Click (PBTL)
SLAU244 – March 2008 TAS5352DDV6EVM 21
