4.16 Frequency Response (BTL)
-8
+10
-6
-4
-2
+0
+2
+4
+6
+8
20 20k50 100 200 500 1k 2k 5k 10k
f-Frequency-Hz
dB
8 W
6 W
4 W
4.17 Frequency Response (PBTL)
-10
10
-9
-8
-7
-6
-5
-4
-3
-2
-1
-0
1
2
3
4
5
6
7
8
9
20 20k50 100 200 500 1k 2k 5k 10k
8 W
4 W
2 W
3 W
f-Frequency-Hz
dB
TAS5352DDV6EVM Performance
Measurement bandwidth filter 80 kHz.
Figure 19. Frequency Response (BTL)
Measurement bandwidth filter 80 kHz.
Figure 20. Frequency Response (PBTL)
