4.14 Idle Noise FFT Spectrum (PBTL)
0 85k5k 10k 15k 20k 25k 30k 35k 40k 45k 50k 55k 60k 65k 70k 75k 80k
0
-140
-130
-120
-110
-100
-90
-80
-70
-60
-50
-40
-30
-20
-10
FFT-dB
f-Frequency-Hz
V =20.6V
REF
4.15 Channel Separation
-80
10
-75
-70
-65
-60
-55
-50
-45
-40
-35
-30
-25
-20
-15
-10
-5
0
5
dB
20 20k50 100 200 500 1k 2k 5k 10k
f-Frequency-Hz
Channel1
Channel2
TAS5352DDV6EVM Performance
Automute disabled – Register x04h set to x60h. Reference voltage is 20.6 V. FFT size 16k.
Figure 17. Idle Noise FFT Spectrum (PBTL)
Channel separation is tested for two channels in a different package, channel 1 and channel 2. 4- Ω loads
are used for both channels. Channel 1 input signal is 0 dBFS; channel 2 is muted. Reference voltage is
20.7 Vrms
Figure 18. Channel Separation
