4.8 THD+N vs Frequency (BTL –8 Ω )
0.001
5
0.002
0.005
0.01
0.02
0.05
0.1
0.2
0.5
1
2
THD+N-TotalHarmonicDistortion+Noise-%
20 20k50 100 200 500 1k 2k 5k 10k
f-Frequency-Hz
58W
-0.2dBFS
10W
1W
4.9 THD+N vs Frequency (PBTL – 2 Ω )
0.001
5
0.002
0.005
0.01
0.02
0.05
0.1
0.2
0.5
1
2
THD+N-TotalHarmonicDistortion+Noise-%
20 20k50 100 200 500 1k 2k 5k 10k
f-Frequency-Hz
201W
-0.2dBFS
10W
1W
TAS5352DDV6EVM Performance
Figure 11. THD+N vs Frequency (BTL –8 Ω )
Figure 12. THD+N vs Frequency (PBTL – 2 Ω )
