A.5 Heat Sink Drawing
1,02 mm ± 0,01 mm
Flatness: 0.001
42,3 mm 67,7 mm 93,1 mm 16,9 mm 0 mm 20,9 mm 38,3 mm
46,3 mm 63,7 mm 71,7 mm 89,1 mm 110,0 mm
0 mm
5,0 mm
A
A
36,0 mm
22,0 mm 14,0 mm 11,5 mm 0,0 mm 24,5 mm
0,0 mm
1,6 mm
3,0 mm
7,0 mm
38,1 mm
2,0 mm
[5plcs]
6,5 mm
[4plcs]
Cross section A-A
MACHINE THESE EDGES AFTER ANODIZING
PROFILE:
MATERIAL:
INTERNAL SCREWTHREADS:
SURFACE:
SURFACETREATMENT:
TOLERANCES:
TIC-HSINK-043profile(1.00)
ALUMINIUM
M3
FREEOFSHARP EDGES
BLACK ANODIZED
± 0,1mm
M0079-01
www.ti.com Heat Sink Drawing
Figure A-13. Heat Sink
