A.3 TAS5142DDV6EVM2 PCB Specification (Version 4.00)
www.ti.com TAS5142DDV6EVM2 PCB Specification (Version 4.00)
Board identification: A799-PCB-001(4.00)
Board type: Double-sided plated-through board
Laminate type: FR4
Laminate thickness: 1,6 mm
Copper thickness: 70 µ m (incl. plating exterior layer)
Copper plating of holes: >25 µ m
Minimum hole diameter : 0,3 mm
Silkscreen, component side: White - remove silkscreen from solder area and pre-tinned areas
Silkscreen, solder side: None
Solder mask, component side: Green
Solder mask solder side: Green
Protective coating: Solder coating and chemical silver on free copper
Electrical test: PCB must be electrically tested
Manufactured to: PERFAG 2E (www.perfag.dk)
Aperture table: PERFAG 10A (www.perfag.dk)
Board size: 115 mm x 137 mm
Comments: See drill information file (5140dri.plt.pdf).
