A.2 TAS5142DDV6EVM2 Parts List
www.ti.com TAS5142DDV6EVM2 Parts List
Table A-1. Parts List
Part Reference QTY Decription Manufacture First MFR P/N
C10 C13 C40 C41 C135
C136 C155 C156 C235 C236
16 Ceramic 10-nF, 50-V, 20% X7R 0603 capacitor BC Components 0603B103M500NT
C255 C256 C335 C336 C355
C356
C11 C12 C14 C17 C21 C22
C25 C26 C50 C101 C102 Ceramic 100-nF, 16-V, 20% X7R 0603
21 BC Components 0603B104M160NT
C104 C105 C201 C202 C204 capacitor
C205 C301 C302 C304 C305
Electrolytic 10- µ F, 16-V, 20% aluminium 2-mm
C51 C924 2 Pansonic ECA1CM100
5-mm M-series general-purpose capacitor
C107 C108 C109 C110 C207
C208 C209 C210 C307 C308 12 Ceramic 33-nF, 25-V, 20% X7R 0603 capacitor BC Components 0603B333M250NT
C309 C310
C113 C115 C117 C119 C213
Ceramic 100-nF, 50-V, 20% X7R 0603
C215 C217 C219 C313 C315 12 Vishay VJ0603Y104MXATW1BC
capacitor
C317 C319
C132 C152 C232 C252 C332 Metal film 470-nF, 63-V, 10% polyester 5-mm MKS 2 0.47uF/105/63Vdc
6 Wima
C352 (W: 4,5 mm L: 7,2 mm) capacitor PCM5
C133 C134 C153 C154 C233
C234 C253 C254 C333 C334
Ceramic 100-nF, 50-V, 20% X7R 0805
C353 C354 C900 C908 C909 23 BC Components 0805B104M500NT
capacitor
C910 C915 C922 C923 C940
C952 C954 C956
C139 C140 C159 C160 C239
C240 C259 C260 C339 C340 12 Ceramic 1-nF, 50-V, 10% NP0 0603 capacitor BC Components 0603N102K500NT
C359 C360
C174 C175 C274 C275 C374 Electrolytic 470- µ F, 35-V, 20% aluminium 5-mm
6 Pansonic EEUFC1V471
C375  m FC-series low-impedance capacitor
C901 C925 C941 C953 C955
6 Ceramic 10-nF, 50-V, 20% X7R 0805 capacitor BC Components 0805B103M500NT
C957
Electrolytic 330- µ F, 35-V 20% aluminium 5-mm
C907 1 Pansonic EEUFC1V331
 m FC-series low-impedance capacitor
Electrolytic 100- µ F, 16-V, 20% aluminium Sang Jing
C911 C913 2 UMR16V107M6.3X5
2,5-mm  mm ultramini-series capacitor Electronics
International
D901 1 1-A, 40-V Schottky diode (SMA) 10MQ040N
Rectifier
HEATSINK630 1 Heat sink for 3 DDV packages, length 110 mm THF-Teknik TIC-HSINK-044(2.00)
J40 1 34 pins/2 rows/2,54-mm pitch vertical male IDC Molex 87256-3411
J60 1 16 pins/2 rows/2,54-mm pitch vertical male IDC Molex 87256-1611
J101 J102 J103 J104 J105 2 pins/1 row/3,96-mm pitch vertical male pin
6 JST BEP-VH
J106 header
4 pins/1 row/3,96-mm pitch vertical male pin
J900 J901 2 JST B4P-VH
header
L130 L131 L150 L151 L230
L231 L250 L251 L330 L331 12 10- µ H ferrite inductor Kwang Sung 8020P-02-100L
L350 L351
220 µ H, 0.5-A, 20% (390mR) magnetically
L900 1 Coil Craft DT3316P-224
shielded ferrite inductor
TAS5142DDV6EVM2 printed circuit board
PCB1 1 Printline A799-PCB-001(4.00)
(version 4.00) - Allegro
100-mA, 45-V PNP small signal transistor
Q40 Q50 2 Philips 9335 897 40215
(SOT-23)
100-mA, 45-V NPN small-signal transistor
Q41 1 Philips 9335 895 70215
(SOT-23)
SLLU095A – April 2007 – Revised April 2008 Design Documents 23
