Jumpers, Connectors, Test Points, Switches www.ti.com
Table 1-1. PCM9211EVM Jumpers, Connectors, Test Points, Switches
(continued)
Connector/Switch/Jumper/Test
Point Description
Jumpers
J1 Mini USB-B connector
J2 Analog audio input
J3 Optical S/PDIF output
J4 Optical S/PDIF input
J5 Coaxial S/PDIF input
Switches
SW1 Reset codec
SW2 Select EVM application
SW3 Select patch script
LEDs
D1 EVM application indicator
D2 EVM patch indicator
D4 PCM9211 ERROR indicator
D5 PCM9211 PCM indicator
Connectors
P3 Odd: GND
P3.2 ERROR/INT0
P3.4 PCM/INT1
P4 Even: MPIO_A
Odd: GND
P5 Even: MPIO_C
Odd: GND
P6 Even: MPIO_B
Odd: GND
P7 Even: GND
P7.1 SCKO
P7.3 BCK
P7.5 LRCK
P7.7 DOUT
