ABSOLUTE MAXIMUM RATINGS
RECOMMENDED OPERATING CONDITIONS
PCM2912
SLES216 – FEBRUARY 2008
This integrated circuit can be damaged by ESD. Texas Instruments recommends that all integrated circuits be handled with
appropriate precautions. Failure to observe proper handling and installation procedures can cause damage.
ESD damage can range from subtle performance degradation to complete device failure. Precision integrated circuits may be more
susceptible to damage because very small parametric changes could cause the device not to meet its published specifications.
over operating free-air temperature range (unless otherwise noted)
(1) (2)
PCM2912 UNIT
Supply voltage V
BUS
– 0.3 to +6.5 V
Ground voltage differences: BGND, PGND, AGND, HGND, DGND ± 0.1 V
Input voltage : V
CCP
, V
CCA
, V
CCL
, V
CCR
, V
DD
– 0.3 to 4 V
PLAY, REC. – 0.3 to 6.5 V
Digital input voltage
D+, D – , XTI, XTO, MMUTE, TEST0, TEST1, POWER, MAMP, SSPND – 0.3 to 4 V
Analog input voltage MBIAS, V
IN
, V
COM1
, V
COM2
, V
OUT
L, V
OUT
R, FR, FL – 0.3 to 4 V
Input current (any pins except supplies) ± 10 mA
Ambient temperature under bias – 40 to 125 ° C
Storage temperature – 55 to 150 ° C
Junction temperature 150 ° C
(1) Stresses beyond those listed under absolute maximum ratings may cause permanent damage to the device. These are stress ratings
only, and functional operation of the device at these or any other conditions beyond those indicated under recommended operating
conditions is not implied. Exposure to absolute – maximum – rated conditions for extended periods may affect device reliability.
(2) All voltage values are with respect to network ground terminal.
over operating free-air temperature range (unless otherwise noted)
MIN NOM MAX UNIT
V
BUS
Supply voltage 4.35 5.00 5.25 V
Analog input voltage, full scale ( – 0 dB) 0.43 V
CCA
Vp-p
Digital input logic family TTL
Digital iInput clock frequency 5.997 6.000 6.003 MHz
Analog output load resistance 32 Ω
Analog output load capacitance 100 pF
Digital output load capacitance 10 pF
T
A
Operating free-air temperature – 25 70 ° C
