THD+Nat-1dBvsSAMPLINGFREQUENCY
0.003
0.004
0.005
0.006
0.007
0.008
0.009
0.01
30 35 40 45 50
f -SamplingFrequency-kHz
S
THD+N-T
otalHarmonicDistortion+Noise-%
DYNAMICRANGEandSNRvsSAMPLINGFREQUENCY
86
88
90
92
94
96
98
30 35 40 45 50
DYNAMICRANGE
SNR
f -SamplingFrequency-kHz
S
DynamicRangeandSNR-dB
DAC
THD+Nat0dBvsTEMPERATURE
0.003
0.004
0.005
0.006
0.007
0.008
0.009
0.01
-50 -25 0 25 50 75 100
T -Free-AirTemperature-°C
A
THD+N-TotalHarmonicDistortion+Noise-%
DYNAMICRANGEandSNRvsTEMPERATURE
86
88
90
92
94
96
-50 -25 0 25 50 75 100
SNR
DYNAMICRANGE
DynamicRangeandSNR-dB
T -Free-AirTemperature-°C
A
PCM2912
SLES216 – FEBRUARY 2008
TYPICAL PERFORMANCE CURVES (continued)
All specifications at T
A
= 25 ° C, V
BUS
= 5 V, f
S
= 44.1 kHz, f
IN
= 1 kHz, 16-bit data, unless otherwise noted.
Figure 20. Figure 21.
Figure 22. Figure 23.
