TYPICAL PERFORMANCE CURVES
ADC
THD+Nat-1dBvsTEMPERATURE
0.003
0.004
0.005
0.006
0.007
0.008
0.009
0.01
-50 -25 0 25 50 75 100
T -Free-AirTemperature-°C
A
THD+N-T
otalHarmonicDistortion+Noise-%
DYNAMICRANGEandSNRvsTEMPERATURE
86
88
90
92
94
96
-50 -25 0 25 50 75 100
SNR
DYNAMICRANGE
T -Free-AirTemperature-°C
A
DynamicRangeandSNR-dB
THD+Nat-1dBvsSUPPLY VOLTAGE
0.003
0.004
0.005
0.006
0.007
0.008
0.009
0.01
4.2 4.4 4.6 4.8 5 5.2 5.4
V -SupplyVoltage-V
BUS
THD+N-TotalHarmonicDistortion+Noise-%
DYNAMICRANGEandSNRvsSUPPLY VOLTAGE
86
88
90
92
94
96
98
4.2 4.4 4.6 4.8 5 5.2 5.4
DYNAMICRANGE
SNR
DynamicRangeandSNR-dB
V -SupplyVoltage-V
BUS
PCM2912
SLES216 – FEBRUARY 2008
All specifications at T
A
= 25 ° C, V
BUS
= 5 V, f
S
= 44.1 kHz, f
IN
= 1 kHz, 16-bit data, unless otherwise noted.
Figure 16. Figure 17.
Figure 18. Figure 19.
