GENERAL DESCRIPTION
USB INTERFACE
PCM2912A
SLES230 – SEPTEMBER 2008 .......................................................................................................................................................................................... www.ti.com
Control data and audio data are transferred to the PCM2912A via D+ (pin 4) and D – (pin 3). All data transferred
to/from the PCM2912A are performed at full speed. Table 1 summarizes the device descriptor. The device
descriptor can be modified on request.
Table 1. Device Descriptor
USB revision 2.0 compliant
Device class 0x00 (device defined in interface level)
Device sub class 0x00 (not specified)
Device protocol 0x00 (not specified)
Max packet size for endpoint 0 8-byte
Vendor ID 0x08BB
Product ID 0x2912
Device release number 0x0100 (1.00)
Number of configurations 1
Vendor string String #1 (refer to Table 3 )
Product string String #2 (refer to Table 3 )
Serial number Not supported
Table 2 lists the configuration descriptor. The configuration descriptor can be modified on request.
Table 2. Configuration Descriptor
Interface Three interfaces
Power attribute 0x80 (Bus powered, no remote wakeup)
Max power 0x32 (100 mA at POWER = Low) / 0xFA (500mA at POWER = High)
Table 3 summarizes the string descriptor. The string descriptor can be modified on request.
Table 3. String Descriptor
#0 0x0409
#1 Burr-Brown from TI
#2 USB audio CODEC
