Datasheet

TYPICAL CHARACTERISTICS: INTERNAL FILTER
ADC Digital Decimation Filter Frequency Response
-160
-120
-80
-40
0
0 8 16 24 32
NormalizedFrequency-xf
S
Amplitude-dB
-100
-80
-60
-40
-20
0
0 0.2 0.4 0.6 0.8 1.0
NormalizedFrequency-xf
S
Amplitude-dB
-0.8
-0.6
-0.4
-0.2
0
0.2
0 0.1 0.2 0.3 0.4 0.5
Amplitude-dB
NormalizedFrequency-xf
S
-20
-16
-12
-8
-4
0
0.46 0.48 0.50 0.52 0.54
Amplitude-dB
NormalizedFrequency-xf
S
PCM2912A
SLES230 – SEPTEMBER 2008 .......................................................................................................................................................................................... www.ti.com
All specifications at T
A
= +25 ° C, V
BUS
= 5 V, f
S
= 44.1 kHz, f
IN
= 1 kHz, and 16-bit data, unless otherwise noted.
OVERALL CHARACTERISTIC STOP BAND ATTENUATION
Figure 1. Figure 2.
PASSBAND RIPPLE TRANSIENT BAND RESPONSE
Figure 3. Figure 4.
