www.ti.com
5.10 RapidIO DEVICEID2 Register (DEVICEID_REG2)
SRIO Registers
Figure 66. RapidIO DEVICEID2 Register (DEVICEID_REG2)
31-24 23-16
Reserved 8BNODEID
R-0x0000 RW-0x00FF
LEGEND: R = Read only; - n = value after reset
15-0
16BNODEID
RW-0xFFFF
LEGEND: R = Read only; - n = value after reset
Table 37. RapidIO DEVICEID2 Register (DEVICEID_REG2) Field Descriptions
Bit Field Value Description
31-24 Reserved Reserved
23-16 8BNODEID This is a secondary supported DeviceID checked against an incoming packet's DestID field.
Typically used for Multi-cast support.
15-0 16BNODEID This is a secondary supported DeviceID checked against an incoming packet's DestID field.
Typically used for Multi-cast support
SPRU976 – March 2006 Serial RapidIO (SRIO) 109
