Datasheet

0 1 2 3 4 5
20
30
40
50
60
70
EFFICIENCY (%)
OUTPUT CURRENT (A)
6 Vin
9 Vin
12 Vin
20 Vin*
0 1 2 3 4 5
0
1
2
3
4
5
6
DISSIPATION (W)
OUTPUT CURRENT (A)
20 Vin*
12 Vin
9 Vin
6 Vin
0 1 2 3 4 5
15
25
35
45
55
65
75
EFFICIENCY (%)
OUTPUT CURRENT (A)
6 Vin
9 Vin
12 Vin
20 Vin
0 1 2 3 4 5
0
1
2
3
4
5
6
DISSIPATION (W)
OUTPUT CURRENT (A)
20 Vin
12 Vin
9 Vin
6 Vin
0 1 2 3 4 5
20
30
40
50
60
70
80
EFFICIENCY (%)
OUTPUT CURRENT (A)
6 Vin
9 Vin
12 Vin
20 Vin
0 1 2 3 4 5
0
1
2
3
4
5
6
DISSIPATION (W)
OUTPUT CURRENT (A)
20 Vin
12 Vin
9 Vin
6 Vin
LMZ22005
www.ti.com SNVS686I –MARCH 2011–REVISED OCTOBER 2013
Typical Performance Characteristics (continued)
Unless otherwise specified, the following conditions apply: V
IN
= 12V; Cin = 2 x 10μF + 1μF X7R Ceramic; C
O
= 220μF
Specialty Polymer + 10 uF Ceramic; Tambient = 25° C for waveforms. Efficiency and dissipation plots marked with * have
cycle skipping at light loads resulting is slightly higher output ripple – See Design Steps for the LMZ22005 Application section.
Efficiency 1.2V Output @ 85°C Ambient Dissipation 1.2V Output @ 85°C Ambient
Figure 33. Figure 34.
Efficiency 1.0V Output @ 85°C Ambient Dissipation 1.0V Output @ 85°C Ambient
Figure 35. Figure 36.
Efficiency 0.8V @ 85°C Ambient Dissipation 0.8V Output @ 85°C Ambient
Figure 37. Figure 38.
Copyright © 2011–2013, Texas Instruments Incorporated Submit Documentation Feedback 11
Product Folder Links: LMZ22005
