LMZ14202EXT
SNVS665F –JUNE 2010–REVISED OCTOBER 2013 www.ti.com
Absolute Maximum Ratings
(1)
VIN, RON to GND -0.3V to 43.5V
EN, FB, SS to GND -0.3V to 7V
Junction Temperature 150°C
Storage Temperature Range -65°C to 150°C
ESD Susceptibility
(2)
± 2 kV
Peak Reflow Case Temperature 245°C
(30 sec)
For soldering specifications, refer to the following document: www.ti.com/lit/snoa549c
(1) Absolute Maximum Ratings are limits beyond which damage to the device may occur. Operating Ratings are conditions under which
operation of the device is intended to be functional. For ensured specifications and test conditions, see the Electrical Characteristics.
(2) The human body model is a 100pF capacitor discharged through a 1.5 kΩ resistor into each pin. Test method is per JESD-22-114.
Operating Ratings
(1)
V
IN
6V to 42V
EN 0V to 6.5V
Operation Junction Temperature −55°C to 125°C
(1) Absolute Maximum Ratings are limits beyond which damage to the device may occur. Operating Ratings are conditions under which
operation of the device is intended to be functional. For ensured specifications and test conditions, see the Electrical Characteristics.
