LMC6482
SNOS674D –NOVEMBER 1997–REVISED MARCH 2013
www.ti.com
AC Electrical Characteristics
Unless otherwise specified, V
+
= 3V, V
−
= 0V, V
CM
= V
O
= V
+
/2, and R
L
> 1M.
LMC6482AI LMC6482I LMC6482M
Parameter Test Conditions Typ
(1)
Units
Limit
(2)
Limit
(2)
Limit
(2)
SR Slew Rate
(3)
0.9 V/μs
GBW Gain-Bandwidth Product 1.0 MHz
T.H.D. Total Harmonic Distortion F = 10kHz, A
V
= −2
0.01 %
R
L
= 10kΩ, V
O
= 2 V
PP
(1) Typical Values represent the most likely parametric norm.
(2) All limits are specified by testing or statistical analysis.
(3) Connected as voltage Follower with 2V step input. Number specified is the slower of either the positive or negative slew rates.
6 Submit Documentation Feedback Copyright © 1997–2013, Texas Instruments Incorporated
Product Folder Links: LMC6482
