LM90
www.ti.com
SNIS126A –MAY 2004–REVISED MARCH 2013
Pin PIN # D1 D2 D3 D4 D5 D6 D7 R1 SNP ESD
Name CLAMP
V
DD
1 x
D+ 2 x
(1)
x x x x x
D− 3 x x x x x x
T_CRIT_ 4 x x x
A
ALERT 6 x x x
SMBData 7 x x x
SMBCLK 8 x
(1) Note: An “x” indicates that the diode exists.
Figure 2. ESD Protection Input Structure
