Operating Ratings
Operating Temperature Range 0°C to +125°C
Electrical Characteristics Temperature Range T
MIN
≤T
A
≤T
MAX
LM86 0°C≤T
A
≤+85°C
Supply Voltage Range (V
DD
) +3.0V to +3.6V
Temperature-to-Digital Converter Characteristics
Unless otherwise noted, these specifications apply for V
DD
=+3.0Vdc to 3.6Vdc. Boldface limits apply for T
A
= T
J
=
T
MIN
≤T
A
≤T
MAX
; all other limits T
A
= T
J
=+25°C, unless otherwise noted.
Parameter Test Conditions Typical Limits Unit
(1) (2)
(Limit)
Temperature Accuracy Using Local Diode T
A
= +25°C to +125°C,
(3)
±1 ±3 °C (max)
Temperature Accuracy Using Remote Diode of T
A
= +30°C T
D
= +80°C ±0.75 °C (max)
mobile Pentium III with typical nonideality of 1.008.
T
A
= +30°C to +50°C T
D
= +60°C to ±1
°C (max)
For other processors email
+100°C
[e-mail] to obtain the
T
A
= +0°C to +85°C T
D
= +25°C to ±3 °C (max)
latest data. (T
D
is the Remote Diode Junction
+125°C
Temperature)
Remote Diode Measurement Resolution 11 Bits
0.125 °C
Local Diode Measurement Resolution 8 Bits
1 °C
Conversion Time of All Temperatures at the Fastest
(4)
31.25 34.4 ms (max)
Setting
Quiescent Current
(5)
SMBus Inactive, 16Hz conversion rate 0.8 1.7 mA (max)
Shutdown 315 µA
D− Source Voltage 0.7 V
Diode Source Current (D+ − D−)=+ 0.65V; high level 160 315 µA (max)
110 µA (min)
Low level 13 20 µA (max)
7 µA (min)
ALERT and T_CRIT_A Output Saturation Voltage I
OUT
= 6.0 mA 0.4 V (max)
Power-On Reset Threshold Measure on V
DD
input, falling edge 2.4 V (max)
1.8 V (min)
Local and Remote HIGH Default Temperature
(6)
+70 °C
settings
Local and Remote LOW Default Temperature
(6)
0 °C
settings
Local and Remote T_CRIT Default Temperature
(6)
+85 °C
Setting
(1) Typical values are at T
A
= 25°C and represent most likely parametric norm.
(2) Limits are guaranteed to National's AOQL (Average Outgoing Quality Level).
(3) Local temperature accuracy does not include the effects of self-heating. The rise in temperature due to self-heating is the product of the
internal power dissipation of the LM86 and the thermal resistance. See
()
for the thermal resistance to be used in the self-heating
calculation.
(4) This specification is provided only to indicate how often temperature data is updated. The LM86 can be read at any time without regard
to conversion state (and will yield last conversion result).
(5) Quiescent current will not increase substantially with an SMBus.
(6) Default values set at power up.
