24V DC Electrical Characteristics
Unless otherwise specified, all limits are ensured for T
J
= 25°C, V
+
= 24V, V
−
= 0V, V
CM
= V
O
= V
+
/2 and R
L
> 1 MΩ to V
+
/2.
Boldface limits apply at the temperature extremes.
LM6152AC LM6154BC
Parameter Test Conditions Typ
(1)
Limit
(2)
LM6152BC Units
Limit
(2)
V
OS
Input Offset Voltage 0.3 2 7 mV
4 9 max
TCV
OS
Input Offset Voltage Average Drift 10 µV/°C
I
B
Input Bias Current 500 nA
I
OS
Input Offset Current 32 nA
R
IN
Input Resistance, CM 0V ≤ V
CM
≤ 23V 60 Meg Ω
CMRR Common Mode Rejection Ratio 0V ≤ V
CM
≤ 23V 94
dB
0V ≤ V
CM
≤ 24V 84
PSRR Power Supply Rejection Ratio 0V ≤ V
CM
≤ 24V 95 dB
V
CM
Input Common-Mode Voltage Range Low −0.25 0 0 V
High 24.25 24 24 V
A
V
Large Signal Voltage Gain R
L
= 10 kΩ 55 V/mV
V
O
Output Swing R
L
= 10 kΩ 0.044 0.075 0.075 V
0.090 0.090 max
23.91 23.8 23.8 V
23.7 23.7 min
I
S
Supply Current Per Amplifier 1.6 2.25 2.25 mA
2.50 2.50 max
(1) Typical Values represent the most likely parametric norm.
(2) All limits are specified by testing or statistical analysis.
24V AC Electrical Characteristics
Unless otherwise specified, all limits are ensured for T
J
= 25°C, V
+
= 24V, V
−
= 0V, V
CM
= V
O
= V
+
/2 and R
L
> 1 MΩ to V
+
/2.
Boldface limits apply at the temperature extremes.
LM6152AC LM6154BC
Parameter Test Conditions Typ
(1)
Limit
(2)
LM6152BC Units
Limit
(2)
GBW Gain-Bandwidth Product f = 100 kHz 80 MHz
(1) Typical Values represent the most likely parametric norm.
(2) All limits are specified by testing or statistical analysis.
