Datasheet

LM6152, LM6154
SNOS752D –MAY 1999–REVISED MARCH 2013 www.ti.com
2.7V DC Electrical Characteristics
Unless otherwise specified, all limits are ensured for T
J
= 25°C, V
+
= 2.7V, V
−
= 0V, V
CM
= V
O
= V
+
/2 and R
L
> 1 MΩ to V
+
/2.
Boldface limits apply at the temperature extremes.
LM6152AC LM6154BC
Parameter Test Conditions Typ
(1)
Limit
(2)
LM6152BC Units
Limit
(2)
V
OS
Input Offset Voltage 0.8 2 5 mV
5 8 max
TCV
OS
Input Offset Voltage Average Drift 10 µV/°C
I
B
Input Bias Current 500 nA
I
OS
Input Offset Current 50 nA
R
IN
Input Resistance, CM 0V ≤ V
CM
≤ 1.8V 30 MΩ
CMRR Common Mode Rejection Ratio 0V ≤ V
CM
≤ 1.8V 88
dB
0V ≤ V
CM
≤ 2.7V 78
PSRR Power Supply Rejection Ratio 3V ≤ V
+
≤ 5V 69 dB
V
CM
Input Common-Mode Voltage Range Low −0.25 0 0 V
High 2.95 2.7 2.7 V
A
V
Large Signal Voltage Gain R
L
= 10 kΩ 5.5 V/mV
V
O
Output Swing R
L
= 10 kΩ 0.032 0.07 0.07 V
0.11 0.11 max
2.68 2.64 2.64 V
2.62 2.62 min
I
S
Supply Current Per Amplifier 1.35 mA
(1) Typical Values represent the most likely parametric norm.
(2) All limits are specified by testing or statistical analysis.
2.7V AC Electrical Characteristics
Unless otherwise specified, all limits are ensured for T
J
= 25°C, V
+
= 2.7V, V
−
= 0V, V
CM
= V
O
= V
+
/2 and R
L
> 1 MΩ to V
+
/2.
Boldface limits apply at the temperature extremes.
LM6152AC LM6154BC
Parameter Test Conditions Typ
(1)
Limit
(2)
LM6152BC Units
Limit
(2)
GBW Gain-Bandwidth Product f = 100 kHz 80 MHz
(1) Typical Values represent the most likely parametric norm.
(2) All limits are specified by testing or statistical analysis.
4 Submit Documentation Feedback Copyright © 1999–2013, Texas Instruments Incorporated
Product Folder Links: LM6152 LM6154
