100k
1M
FREQUENCY (Hz)
-100
-90
-70
-60
-50
-40
-20
-10
0
HD (dBc)
-30
-80
HD2
HD3
THD
V
S
= ±5V
A
V
= -1
V
IN
= 5 V
PP
R
L
= 10 k:
LM6152, LM6154
SNOS752D –MAY 1999–REVISED MARCH 2013
www.ti.com
Typical Performance Characteristics (continued)
Distortion vs. Frequency
Figure 27.
