Bill of Materials www.ti.com
8 Bill of Materials
Table 1. Bill of Materials
ID Description Manufacturer Mfgr Part Number
U1 IC; Ideal OR-ing Diode Controller Texas Instruments LM5050
Capacitor: MLCC; 1.0µF; ±10%; 100V; X7R;
C1 Vishay/Vitramon VJ1825Y105KBBAT4X
1825
Capacitor: 22 µF; ±20%; 100V; Aluminum
C2 Panasonic/ECG EEE-HA2A220P
Electrolytic; SMT
C3 Not Installed - -
ON Semiconductor SS16T3G
D1 Diode: Schottky Barrier Rectifier; 1A: 60V; SMA
Micro Commercial Components SS16-TP
D2 Diode: TVS; Unidirectional; 600W; 60V; SMB Diodes Inc SMBJ60A-13-F
MOSFET: N-Channel; 100V; 40A; 0.025Ω;
Q1 Vishay/Siliconix SUM40N10-30-E3
D
2
PAK
R1 Not Installed - -
Vishay/Dale CRCW060310K0FKEA
Resistor: 10.0 kΩ; 0.10W; ±1%; 100ppm; Thick
R2
Film; 0603
ROHM Semiconductor MCR03EZPFX1002
VIN
VOUT
Terminal: 6-32 Screw; Vertical; Snap-In PCB
Keystone Electronics 7693
Mount; 15A
GND
GND
Off
nPGD
Test Point Terminal: 0.040in Dia Mtg Hole;
V
LOGIC
Keystone Electronics 5012
White
GND
GND
6
AN-2051 LM5050-2EVAL Evaluation Board SNVA435A–November 2010–Revised May 2013
