Electrical Performance Specifications
www.ti.com
3 Electrical Performance Specifications
Table 1. LM3447-A19-120VEVM Electrical Performance Specifications
PARAMETER TEST CONDITIONS MIN TYP MAX UNITS
Input Characteristics
Voltage range 90 120 135 V
Maximum input current 100 mA
Output Characteristics
Output voltage, V
OUT
9 to 10 LED’s 28 30 32 V
Output load current, I
OUT
240 275 310 mA
Output current ripple V
IN
= 120 V
AC
100 mApp
Output over voltage 36 V
Systems Characteristics
Switching frequency 75 kHz
Full-load efficiency V
IN
= 120 V
AC
82%
Power factor, PF 0.98
