User's Guide
SLUU937–May 2012
LM3447-A19-120VEVM is a Phase-Dimmable, Primary-Side
Regulated LED Driver
1 Introduction
The LM3447-A19-120VEVM is a 10-W, 120-V
AC
isolated dimmable LED driver whose form factor intended
for A19/R27 applications.
2 Description
The LM3447-A19-120VEVM is a primary-side power regulated PFC controller used for commercial and
residential phase-cut dimmer compatible LED lamp drivers. The LM3447-A19-120VEVM uses fixed
frequency valley switching operation resulting in discontinuous current operation.
2.1 Typical Applications
• A19 Bulb Form Factor
• R27 Bulb Form Factor
2.2 Features
• Primary-Side Control
• Leading and Trailing Edge Compatible
• 50:1 Dimming Range
• Valley Switching
• Fixed Frequency Discontinuous Operation
• Thermal Foldback
• PFC
• Efficient Triac Hold Current Operation
• LED Short and Open Circuit Detection
• Thermal Foldback
• Constant Power Operation
3
