Turn-on angle vs. Total Input Power
0.00
2.00
4.00
6.00
8.00
10.00
12.00
5 55 105 155
Turn-on angle (degrees)
Total Input Power (W)
Performance Data and Typical Characteristic Curves
www.ti.com
7.8 Turn-On Angle vs Input Power
Figure 11. Turn-On Angle vs. Input Power
7.9 Input/Output Current and Line Voltage Waveforms vs. Dimmer Setting
Figure 12. Dimmer Full
(Ch4- LED current Ch3 - rectified line voltage Ch1 – line current)
12
LM3447-A19-120VEVM is a Phase-Dimmable, Primary-Side Regulated LED SLUU937–May 2012
Driver
